Post-Tensioning System Bonded Monostrand Anchor Barrel and Wedges (Call us: Mobile No: +8613673713569) PRODUCT DESCRIPTI;
Basic Info.
Model NO. | YJM15(13)-1 |
Complete Anchorage System | Anchor Head, Wedge, Bearing Plate, Spring Ring |
Certificate | SGS, BV, ISO9001-2008 |
Color | Galvanized or Black, or Non-Galvanized Color |
Material | 20crmnti, 45# Steel, 40cr, Alloy Steel, etc. |
Transport Package | Ply Wooden Case or Carton, or Container |
Specification | SGS, ISO9001-2008, BV |
Trademark | CNM |
Origin | Hennan Province |
HS Code | 7316000000 |
Production Capacity | 1000000 Pieces Per Year |
Product Description
Post-Tensioning System Bonded Monostrand Anchor Barrel and Wedges (Call us: Mobile No: +8613673713569)PRODUCT DESCRIPTIONS (Call us: Mobile No: +8613673713569)
1. Model: YJM5(5mm), YJM7(7mm), YJM9(9mm), YJM13(12.7mm, 12.9mm), YJM15(15.24mm, 15.7mm),YJM18, YJM22. 2. For Strand(Wire) Diameter: 5mm, 7mm, 9mm, 9.52mm, 12.7mm, 12.9mm, 15.24mm, 15.7mm, 17.8mm, 22mm, etc.
3. Anchor Type: Open Type
4. Materials: Anchor Head Materials: 45#, 40Cr,Steel, Wedges Materials: 20CrMnTi carbon steel.
5. Anchor Head Hardness: HRC25-36. Wedges Hardness: HRC58-65.6. Full Complete Parts: Flat Anchor Casting Head, Wedges, Anchor Bearing Plate, Spiral Spring Ring.
Henan Prestressing Equipment Co.,Limited manufacture full complete post tension components, materials and post tension equipment for buildings and bridge construction. Kindly please contact with us by our official or call us: Mobile Phone: +8613673713569.
APPLICATIONS(Call us: Mobile No: +8613673713569)
1). For Buildings: Housing, Commercial Buldings, High Rise Buildings.2). For Municipal Engineering: Railway, Highway, Over Head Fast Speed Way, Metro Way, High-speed Railway, etc.3). For Projects: Mining, Piling, Foundation, Slope and Rock Reinforcement, Hydropower Station, Anchoring Engineers, Water Conservancy Project, Oil or Gas Tank, etc.
Contact with us: call us: Mobile No: +8613673713569.
FEATURES(Call us: Mobile No: +8613673713569)
YJM anchorage system is consists of Stresed End Anchor System(Including Stressed End Anchor Head/ Blocks, Anchor Wedges, Anchor Bearing Plate, Spiral Steel Reinforcing Rings) and Dead End(Fixing End) Anchor System(including Dead end anchor, Anchor Wedges, Steel Plate, Spiral Steel Reinforcing Rings). It is widely used in Prestressing and Post Tensioning construction.
YJM series of anchor system is work with 5mm to 10mm pc steel wire and 12.7mm, 15.24mm pc strand cable. The detail specifications see as followings: 1). YJM5 applies to 5mm, 5.2mm smooth surfase and spiral ribbed pc steel wire.2). YJM6 applies to 6mm smooth surfase and spiral ribbed pc steel wire.3). YJM7 applies to 7mm smooth surfase and spiral ribbed pc steel wire.4). YJM8 applies to 6mm smooth surfase and spiral ribbed pc steel wire.5). YJM9 applies to 9mm smooth surfase and spiral ribbed pc steel wire.6). YJM10 applies to 10mm smooth surfase and spiral ribbed pc steel wire, and 9.3mm, 9.53mm pc strand.7). YJM11 applies to 10.8mm and 11mm pc strand.
8). YJM13 applies to 12.7mm, 12.5mm & 12.9mm pc strand.
9). YJM15 applies to 15.2/15.24mm, 15.7mm pc strand.
10). YJM18 applies to 17.8mm pc strand.11). YJM22 applies to 21.6/21.8mm pc strand.
Call us: Mobile No: +8613673713569
OUR ADVANTAGES (Call us: Mobile No: +8613673713569)
Henan Prestressing Equipment Co.,Limited manufacture full complete post tension components, materials and post tension equipment for buildings and bridge construction. Kindly please call us: Mobile Phone. +8613673713569.Our Product Ranges:1. Anchor System: unbonded monostrand anchor system, multistrands anchor system, flat anchor system, arch type flat anchor, anchor barrel and wedges, ground anchor, rock and soil anchor, anchor wedges, anchor bearing plate, spiral reinforcing rings.2. PC Strand System: unbonded pc strand, bonded pc strand, 12.7mm prestressed cable, 15.24mm prestressed strand, epoxy coated pc strand,galvanized pc strand, 6mm, 7mm, 9mm pc steel wire.3. Duct System: galvanized metal duct, HDPE plastic duct, curved type galvanized metal duct, flat duct, corrugated pipe. 4. Heavy equipment: bridge girder launching machine, drilling rig, bridge girder transporterContact with us: call us: Mobile No: +8613673713569.
Samples Exhibiton for Different Kinds of Anchorage System And PC Strand (Call us: Mobile No: +8613673713569)
Prestressed Strand, Unbonded HDPE Coated Prestressed Cable, Galvanized PC Strand, PC Steel Wire
TECHNICAL DATA(Call us: Mobile No: +8613673713569)
YJM13-QYM Stress End Anchor System Technical Data:
ΦD | B | A | L | ΦC | ΦG | ΦH | d | n | |||
YJM13-QYM1 | 1 | 40 | 45 | 90 | 60 | Φ35 | 60 | 30 | 6 | 3 | QYC270 |
YJM13-QYM2 | 2 | 78 | 46 | 120 | 80 | Φ40 | 110 | 30 | 6 | 3 | YDC 650 |
YJM13-QYM3 | 3 | 78 | 46 | 120 | 80 | Φ45 | 120 | 30 | 8 | 3 | YDC 650 |
YJM13-QYM4 | 4 | 85 | 46 | 130 | 85 | Φ50 | 130 | 40 | 10 | 4 | YDC 1000 |
YJM13-QYM5 | 5 | 92 | 46 | 140 | 97 | Φ50 | 140 | 50 | 12 | 4 | YDC 1500 |
YJM13-QYM6/7 | 6/7 | 103 | 48 | 160 | 120 | Φ60 | 160 | 50 | 12 | 4 | YDC 1500 |
YJM13-QYM8 | 8 | 116 | 48 | 170 | 120 | Φ60 | 170 | 50 | 12 | 4 | YDC 2000 |
YJM13-QYM9 | 9 | 126 | 50 | 180 | 150 | Φ70 | 180 | 50 | 12 | 4 | YDC 2000 |
YJM13-QYM10 | 10 | 136 | 50 | 192 | 160 | Φ80 | 180 | 50 | 14 | 4 | YDC 2500 |
YJM13-QYM11/12 | 11/12 | 136 | 50 | 192 | 160 | Φ80 | 190 | 50 | 14 | 5 | YDC 2500 |
YJM13-QYM13 | 13 | 146 | 50 | 210 | 170 | Φ80 | 210 | 50 | 14 | 5 | YDC 3000 |
YJM13-QYM14 | 14 | 146 | 55 | 210 | 170 | Φ80 | 210 | 50 | 14 | 5 | YDC 3000 |
YJM13-QYM15 | 15 | 166 | 55 | 220 | 205 | Φ90 | 220 | 60 | 14 | 5 | YDC 3500 |
YJM13-QYM16 | 16 | 176 | 55 | 250 | 220 | Φ90 | 250 | 60 | 14 | 5 | YDC 3500 |
YJM13-QYM17 | 17 | 176 | 60 | 250 | 230 | Φ90 | 250 | 60 | 16 | 5 | YDC 3500 |
YJM13-QYM18 | 18 | 176 | 60 | 250 | 230 | Φ90 | 250 | 60 | 16 | 5 | YDC 4000 |
YJM13-QYM19 | 19 | 176 | 60 | 250 | 230 | Φ90 | 250 | 60 | 16 | 5 | YDC 4000 |
YJM13-QYM22 | 22 | 186 | 65 | 260 | 240 | Φ200 | 260 | 60 | 16 | 6 | YDC 5000 |
YJM13-QYM25 | 25 | 206 | 70 | 280 | 240 | Φ200 | 280 | 60 | 18 | 6 | YDC 5500 |
YJM13-QYM Stress End Anchor System Technical Data(Call us: Mobile No: +8613673713569)
Anchor Model | The Number of PC Strand | Anchor Head/Plate | Corrugated Pipe I.D. | Anchor Barrel | Spiral Reinforcement | Tension Jack Model | |
A x B x ΦD | ΦD | ΦE x F | ΦG x ΦH x L | Cycles | |||
YJM15-1 | 1 | 80x80xΦ12 | Φ50 | Φ45x45 | 70x Φ6x30 | 4 | QYC270 |
YJM15-2 | 2 | 135x70xΦ58 | Φ50 | Φ78x45 | 100x Φ8x40 | 4 | YDC 1000 |
YJM15-3 | 3 | 135x70xΦ58 | Φ50 | Φ88x48 | 100x Φ8x40 | 4 | YDC 1000 |
YJM15-4 | 4 | 136x80xΦ62 | Φ55 | Φ98x48 | 130x Φ10x40 | 4 | YDC 1000 |
YJM15-5 | 5 | 146x80xΦ62 | Φ55 | Φ103x48 | 140x Φ10x50 | 4 | YDC 1100 |
YJM15-6 | 6 | 162x100xΦ78 | Φ70 | Φ117x48 | 160x Φ12x50 | 4 | YDC 1500 |
YJM15-7 | 7 | 162x100xΦ78 | Φ70 | Φ117x50 | 160x Φ12x50 | 4 | YDC 1500 |
YJM15-8 | 8 | 176x120xΦ88 | Φ80 | Φ127x50 | 170x Φ14x50 | 5 | YDC 2000 |
YJM15-9 | 9 | 183x120xΦ90 | Φ80 | Φ137x50 | 180x Φ14x50 | 5 | YDC 2000 |
YJM15-10 | 10 | 210x120xΦ100 | Φ90 | Φ147x50 | 210x Φ14x60 | 5 | YDC 2500 |
YJM15-11 | 11 | 210x140xΦ100 | Φ90 | Φ157x50 | 210x Φ14x60 | 5 | YDC 2500 |
YJM15-12 | 12 | 210x140xΦ100 | Φ90 | Φ157x50 | 210x Φ14x60 | 5 | YDC 2500 |
YJM15-13 | 13 | 210x140xΦ100 | Φ90 | Φ157x55 | 210x Φ14x60 | 5 | YDC 3000 |
YJM15-14 | 14 | 234x160xΦ100 | Φ90 | Φ167x60 | 230x Φ16x60 | 5 | YDC 3000 |
YJM15-15 | 15 | 234x160xΦ100 | Φ90 | Φ167x60 | 230x Φ16x60 | 5 | YDC 3500 |
YJM15-16 | 16 | 244x180xΦ100 | Φ90 | Φ177x60 | 230x Φ16x60 | 5 | YDC 3500 |
YJM15-17 | 17 | 250x180xΦ100 | Φ90 | Φ187x65 | 230x Φ16x60 | 5 | YDC 3500 |
YJM15-18 | 18 | 265x200xΦ110 | Φ100 | Φ187x65 | 250x Φ16x60 | 5 | YDC 4000 |
YJM15-19 | 19 | 265x200xΦ110 | Φ100 | Φ187x65 | 250x Φ16x60 | 6 | YDC 4000 |
YJM15-20/21/22 | 20/21/22 | 310x240xΦ130 | Φ120 | Φ215x70 | 300x Φ18x60 | 6 | YDC 4600 |
YJM15-23 | 23 | 310x240xΦ140 | Φ130 | Φ217x70 | 300x Φ22x60 | 6 | YDC 5000 |
YJM15-25/26/27 | 25/26/27 | 350x290xΦ140 | Φ130 | Φ260x90 | 310x Φ22x60 | 7 | YDC 6500 |
YJM15-30/31 | 30/31 | 370x290xΦ150 | Φ140 | Φ290x105 | 400x Φ22x60 | 8 | YDC 6500 |
YJM15-34/37 | 34/37 | 465x340xΦ170 | Φ160 | Φ320x112 | 450x Φ22x60 | 8 | YDC 8000 |
YJM15-43/44 | 43/44 | 500x450xΦ170 | Φ160 | Φ345x130 | 470x Φ22x60 | 8 | YDC 10000 |
YJM15-54/55 | 54/55 | 500x510xΦ170 | Φ160 | Φ380x160 | 520x Φ24x61 | 8 | YDC 12000 |
FAQ(Call us: Mobile No: +8613673713569)
1): Q: Do you supply OEM Service or Customized-made Anchorage System?A Yes, we do. Actually, we have cooperated with many famous PT Supplier in whole world.Just send us your drawings when need to be customized.2) Q: Do you provide free samples?
A: Yes, sure, we provide free samles for your testing.3) Q: How is the delivery lead time:A: Goods in stock: within 3 days, Goods out of stock(7 days), Goods need to be customized(10-15 days).4) What is your Minimum Order?
A: MOQ: 100 pieces.5) Q: Payment Terms?A TT, LC, Western Union, Paypal, etc.6) Q: How to transport the goods:A: by shipping, airflight, express.
Let's have a quick communications for business by following:Mobile No.: +8613673713569Jason Wang
